1324 - Baluster

SKU Width Height Projection "M" Dimension CAD PDF drawings CAD DWG drawings CAD DXF drawings
1324 4 1/2″20 1/8″4 1/2″13/16"PDFDWGDXF

Dimension M“M” Dimension

‘’M’’ dimension is provided to help you figure out the spacing of your balusters in keeping with the Building Code’s 4’’ Ball Rule which requires that a ball measuring 4’’ in diameter should not be able to pass between the balusters.

Additional notes

Hardware is sold separately.

Installation guides

General Installation Guide
Rail Installation Guide - Standard Fasteners
Rail Installation Guide - Toggle Bolt Spring
Stair Rail Installation Guide

SKU: 1324 Category:

Description

Dimension M“M” Dimension

‘’M’’ dimension is provided to help you figure out the spacing of your balusters in keeping with the Building Code’s 4’’ Ball Rule which requires that a ball measuring 4’’ in diameter should not be able to pass between the balusters.

Additional information

Width

4 1/2″

Height

20 1/8″

Projection

4 1/2″

"M" Dimension

13/16"

CAD PDF drawings

–, 9251

CAD DWG drawings

–, 9253

CAD DXF drawings

–, 9255
