5557 - Crosshead
SKU |
Width
|
Height
|
Projection
|
CAD PDF drawings
|
CAD DWG drawings
|
CAD DXF drawings
|
5557-29.875 |
29 7/8" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-35.875 |
35 7/8" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-39.875 |
39 7/8" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-45.75 |
45 3/4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-47.75 |
47 3/4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-49.875 |
49 7/8" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-51.75 |
51 3/4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-55.75 |
55 3/4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-59.75 |
59 3 /4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-65.75 |
65 3/4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-67.75 |
67 3/4" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-71.625 |
71 5/8" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-75.625 |
75 5/8" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-79.5 |
79 1/2" | 6 3/8″ | 3 1/8″ | - | - | - |
|
5557-S |
up to 142" | 6 3/8″ | 3 1/8″ | PDF | DWG | DXF |
|
