1211-B - Support Block

SKU Width Height Projection Dimensions CAD PDF drawings CAD DWG drawings CAD DXF drawings
1211-B 7″2 1/8″1 5/8″L:11 3/8″H:18 3/8″P:1 1/4″PDFDWGDXF

Additional notes

A support block must be used at the center point of all bottom railings exceeding 48″ (1,22 m).

Installation guides

General Installation Guide
Rail Installation Guide - Standard Fasteners
Rail Installation Guide - Toggle Bolt Spring
Stair Rail Installation Guide

SKU: 1211-B Category:

Additional information

Width

7″

Height

2 1/8″

Projection

1 5/8″

Dimensions

L:11 3/8″H:18 3/8″P:1 1/4″

CAD PDF drawings

–, 8366

CAD DWG drawings

–, 8368

CAD DXF drawings

–, 8370
