| SKU | Width | Height | Dimensions | Pedestal height | CAD PDF drawings | CAD DWG drawings | CAD DXF drawings | |
|---|---|---|---|---|---|---|---|---|
| 1500-R-1228-7 | 12" | 84" | P:1"H:4'Lg:10' | 29" | - | - | - | |
| 1500-R-1228-8 | 12" | 96" | P:1"H:4'Lg:12' | 29" | - | - | - | |
| 1500-R-1228-9 | 12" | 108" | P:1"H:4'Lg:18' | 29" | DWG | DXF | ||
| 1500-R-1228-10 | 12" | 120" | P:1 1/4"H:4'Lg:8' | 29" | - | - | - | |
| 1500-R-1236-7 | 12" | 84" | 37" | - | - | - | ||
| 1500-R-1236-8 | 12" | 96" | 37" | - | - | - | ||
| 1500-R-1236-9 | 12" | 108" | 37" | DWG | DXF | |||
| 1500-R-1236-10 | 12" | 120" | 37" | - | - | - |
Guide d'installation général
Guide d'installation pour colonnes 1500-F, 1500-R, 1502-F & 1502-R
| Width | 12" |
|---|---|
| Height | 108", 120", 84", 96" |
| Dimensions | P:1 1/4"H:4'Lg:8', P:1"H:4'Lg:10', P:1"H:4'Lg:12', P:1"H:4'Lg:18', P:1/2"H:4'Lg:10', P:1/2"H:4'Lg:12', P:1/2"H:4'Lg:18', P:1/2"H:4'Lg:8' |
| Pedestal height | 29", 37" |
| CAD PDF drawings | 9586, 9602, – |
| CAD DWG drawings | 9588, 9604, – |
| CAD DXF drawings | -, 9590, 9606 |
